60 Cells 250 Watt Polycrystalline Solar Panel Module
Poly-crystalline modules designed for residential and utility applications, rooftop and ground mount.
Anti-reflective and self-cleaning surface reduces power loss from dirt and dust.
Excellent mechnical load resistance: certified to with stand high wind loads(2400Pa) and snow load(5400Pa)
| ELECTRICAL DATA(STC) | ASP660xxx-60 xxx = Peak Power Watts | |||||
| Peak Power Watts(Pmax/W) | 255 | 260 | 265 | 270 | 275 | 280 |
| Power Output Tolerance(W) | 0~+5 | |||||
| Maximum Power Voltage(Vmp/V) | 30.07 | 31.1 | 31.4 | 31.7 | 32 | 32.3 |
| Maximum Power Current(Imp/A) | 8.3 | 8.37 | 8.44 | 8.52 | 8.61 | 8.69 |
| Open Circuit Voltage(Voc/V) | 37.06 | 38.1 | 38.6 | 38.8 | 39.1 | 39.4 |
| Short Circuit Current(Isc/A) | 8.93 | 8.98 | 9.03 | 9.09 | 9.15 | 9.2 |
| Module Efficiency(%) | 15.67 | 15.89 | 16.19 | 16.5 | 16.8 | 17.11 |
Ensure Colour and Power Difference.
Ensure high yields,consistent performance and durability,
First of 52 steps strict quality control and inspection process.
Before and After Lamination.
Most stringent acceptance criteria and tightest tolerance,
Intelligent alarm and stop mechanism in case of any deviation or
errors.
Before and Following Lamination
Ensure "Zero" micro crack monitoring before final inspection,
Continuous line monitoring and video/photo record for each cell and
panel.
Defects Objective Before Shipment.
Most stringent acceptance criteria and tightest tolerance,
Ensure the best modules on the market- guaranteed!
Ensure 3% Positive Power Tolerance
Comprehensive QC information management system with barcode
ID.Quality traceable system in place to allow quality data flow
constantly.
| Model | ASP660xxx-60 (Size:1640*992*35mm) |
| Modules per box | 30 pcs |
| Modules per 40' High container | 840 pcs |
| The Above packing information contained in this web is subject to change without notice. We will offer wooden box packing with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests. | |
|
|
