5BB Poly Solar Cells 300w 310w 320w PV Solar Panels
Product Description
| Model | JX310P | JX315P | JX320P | JX325P | JX330P |
| Rate Maximum Powe at STC | 310W | 315W | 320W | 325W | 330W |
| Maximum Power Voltage(Vmp) | 37.22V | 37.33V | 37.4V | 37.6V | 37.8V |
| Maximum Power Current (Imp) | 8.33A | 8.46A | 8.56A | 8.66A | 8.74A |
| Open Circuit Voltage (Voc) | 46.02V | 46.1V | 46.4V | 46.7V | 46.9V |
| Short Circuit Current (Isc) | 8.71A | 9.03A | 9.05A | 9.10A | 9.14A |
| Module Efficiency | 16.00% | 16.19% | 16.49% | 16.75% | 17.01% |
| Power Tolerance | 0~+3% | 0~+3% | 0~+3% | 0~+3% | 0~+3% |
| STC | Irradiance 1000w/m2,module temperature 25℃,air mass 1.5 | ||||
| Mechanical Parameters | ||||
| Cell Type | Poly-crystalline 156*156mm(6 inch) | |||
| No.of Cells | 72(6×12) | |||
| Dimension | 1956*992*40mm | |||
| Glass | 3.2mm,high transmission,low iron,tempered glass | |||
| Junction Box | IP65 & IP67 Rated | |||
| Output Cable | Section size:4mm2,length:900mm | |||
| Frame | anodized aluminum alloy | |||
| No.of Bypass Diodes | 3&6 | |||
| Connector | MC4 compatible | |||
| Weight | 22.5kgs | |||
|
|
